Fanso ER14505H

Fanso ER14505H

Fanso ER14505H AA size 3.6V 2700mAh High Capacity Lithium Thionyl Chloride Battery - Bobbin Type (MBU)

ER14505H primary lithium battery.

Wuhan Fanso high capacity range.

Features:

  • Long shelf life: self discharge rate less than 1% at 25°C.
  • High energy density (700Wh/kg).
  • Long operating life.
  • Stainless steel container and end caps.
  • Wide temperature range: -55ºC ~ +85ºC.
  • Hermetic glass-to-metal sealing.
  • Non-flammable electrolyte.
  • Compliant with IEC86-4 safety standard.
  • UL Component Recognition MH46165.
  • High and stable operating voltage.

Suitable for applications including:
  • Utility metering
  • Alarm and security devices
  • Memory backup power
  • Professional electronics
  • GPS tracking system
  • Military system
  • Automotive electronics
  • Real-time clock


Store in a cool dry place not exceeding +30ºC.


SHARE:
Selling Unit EACH
Model No ER14505H
Brand Fanso brand logo
Description Fanso ER14505H AA size 3.6V 2700mAh High Capacity Lithium Thionyl Chloride Battery - Bobbin Type (MBU)
Application Memory Back Up (MBU), IOT Devices, Smart Meters, Security
Chemistry Lithium Thionyl Chloride
Voltage 3.6V
Watt Hour 9.72Wh
Nominal Capacity 2.7Ah
Maximum Continuous Discharge Current 60mA
Maximum Pulse Discharge Current 150mA
Size AA
Width 14.5mm
Height 50.5mm
Weight 19g
Inner Quantity 30
Outer Quantity 600
Categories Portable Power Product
Batteries Primary (Non-Rechargeable)
Lithium Batteries
Lithium Thionyl Chloride Batteries
Lithium Thionyl Chloride Cylindrical Bobbin-MBU type
Memory Back Up (MBU) Batteries
Data Sheet Datasheet PDF Thumbnail icon

Login to MI Link for pricing
Login for Pricing
MI Link is a dealer-only portal. If you are not a current MI account holder register for an account

Shipping restrictions

SHIPPING RESTRICTIONS APPLY

Due to IATA and individual airline regulations, this item may only be shipped by surface (road/sea) freight.

NON DG UN3090 LITHIUM METAL BATTERIES - Contains cells/batteries exempted from ADG 7.7 & IMDG Code 2020 using Special Provision 188.

Further information on freight & postal regulations for lithium / lithium-based and other battery chemistries can be found on our battery transportation page.
