Smart Lithium Battery designed for today's advanced systems

Introducing the Smart IP67 rated 12V 100Ah LiFePO4 battery from Pylontech. Featuring an advanced BMS to provide safety and scalability, Handy on/off battery to isolate when not in use, Bluetooth, Can & RS485 connectivity, the RT12100G31 has been developed to provide the ultimate storage solution for Marine, RV/Caravan, 4x4 and many other solar storage applications.

Features & Benefits

Smart Lithium Battery

The most adaptable 12.8V Lithium battery solution on the market today. Featuring advanced LiFePO4 technology, embedded BMS to provide exceptional performance.

IP67 Rated

Perfect for Marine use, or externally mounting in RV/4X4 applications.

Bluetooth

Easy system configuration and real-time monitoring from your smart device. Configure your series/parallel systems, view individual battery status and remotely activate the heater function for the palm of your hand.

Scalable

Fully Scalable to adapt to your growing storage requirements. Up to 1S/1-16P 12V 100Ah to 1600Ah, 2S/1-8P 24V 100Ah to 800Ah, and 4S/1-4P 48V 100Ah to 400Ah.

Interlinking Cables

Interlinking communication cables to ensure all batteries in your system are working together to reduce failures caused by battery imbalances.

On / Off Button

Reduce unnecessary usage by isolating your batteries when not in use.

CAN/RS485

Communications protocols to interface with your existing monitoring systems & Marine Glass Bridges *via Victron Energy GX

Advanced BMS

Advanced BMS with auto-balancing and advanced safety protocols to keep you safe and extend service life

100A Maximum Continuous Discharge

With a 200A Peak discharge capability for 30 seconds. Discharge power also increases as your battery system size grows.

Wide Operating Temp Range

Capable of sub-zero temperature usage thanks to the in-built heating pad (-20°C to +60°C).

Specifications

Cycle life: >6000 cycles (90% DoD) @ 25°C
Max. continuous discharge current*: 100A
Max. pulse discharge current: 200A (max 30s)
Charge voltage: 14.0V - 14.4V (14.4V recommended)
Max. continuous charge current: 100A
Discharge Cut-Off Voltage: 10V
Operating Discharge temperature: -20°C to +60°C
Operating Charge temperature: -0°C to +60°C
Storage temperature: -40°C to +60°C
Series* Connection Allowed: Up to 4S (up to 16 batteries eg 4S4P)
Parallel* Connection Allowed: Up to 16P @ 12V (12V 16P, 24V 8P, 48V 4P max)
Protection: Short Circuit Protection
Over/Under Voltage Protection
Over/Under Temperature protection
Over Current protection
Certifications: UN38.3 Approved,
SAE J930,
SAE J1455,
UL 1973,
IEC62619,
FCC,
CE,
Bluetooth SIG
Case Structure: Rugged mechanical design
Ingress Rating: IP67 Rating
Warranty: 5 Years
Size: Standard G31 (W325mm x D173.5mm x H226mm)

* Max Continuous discharge current 1.0°C up to 8 batteries, 0.8°C for 9-16 batteries in parallel

Highly scalable for your growing requirements

16 units scalable system series/parallel. Max uo to 4S4P, 2S8P, 1S16P

More Information

Datasheet
Download
Manual
Download
Product Flyer
Download
Bluetooth Man.
Download
Get it on Google Play

Where to Buy?

Contact us and provide your location and we will put you in touch with your nearest retailer.
