01 Aug 2024
VoltGo Lithium Batteries
VoltGo has landed in Australia and Master Instruments is proud & excited to be a distribution partner for their Elite Series Lithium battery range.
With their deeply entrenched ethos of driving global renewable energy, VoltGo's Elite series batteries raise the benchmark for performance and safety in mobile and stationary Lithium battery installations.
With 6 models offering a diverse range of voltage & capacity options, available in 3 footprints, all feature a ruggedised IP65 rated flame retardant casing, and are suitable for use in a diverse array of applications such as 4x4, Caravan & RV, Marine applications, food truck and commercial vehicles, remote power and off-grid installations, emergency backup and power systems to name a few.
A lightweight & maintenance free alternative to traditional lead acid batteries, the VoltGo Elite series also provides exceptional service life of over 6000 cycles to 80% Depth of Discharge to reduce the strain on your wallet, Bluetooth output to enable real-time monitoring from a smart device and passive cell balancing to ensure all batteries within your system are working together for longer.
The advanced safety features include an intelligent BMS with protections against short circuit, over/under voltage and over/under temperature fluctuations, all encased in flame retardant ABS casing with an in-built aerosol fire suppression system as a final line of defence to ensure safe operation and swift fault mitigation.
All VoltGo Elite series batteries come with a 10 year limited warranty for added peace of mind.
Easy System Expansion
This VoltGo Elite Series Lithium Iron Phosphate battery can be connected in up to 16 in parallel (16P) - NO SERIES Connection allowed. *See Product User Manual or Datasheet for more information..
*VLRV1280A up to 4S or 4P only
Let Your Battery Talk to You
No more guesswork! Connect to your battery from your phone or tablet for real-time monitoring of your battery's status, including voltage, state of charge, consumption, health and cycle count.
Intelligent BMS
Worry less about your battery with the smart battery management system, which offers protection against short circuit, over/under voltage and over/under temperature fluctuations. When multiple modules are used in a system, the self-balancing function also keep all batteries working together to extended service life.
Fire Protections
VoltGo batteries lead the way in safety with their UL94 V-0 rated flame retardent cases, and in-built aerosol fire suppression system as the last line of defence to ensure safe operation and swift fault mitigation.
Smart Integration
The top mounted panel features an ON/OFF switch, State of Charge indicator, Alarm and Function LEDs. The 2 CAN/RS485 Comms Ports integrate your VoltGo batteries into existing control/monitoring systems, via a Victron Energy GX device*, to give full visibility and tracking. *Not Applicable to VLRV1280A
SMART-GO Fastening System
Removable handy brackets come fixed to the batteries for use as handles during transport. VoltGo batteries come standard with numerous nutserts fitted within the case to utilise the included brackets and fish plates to securely fasten your battery to the floor, wall, or to other batteries when connected together. Expandable up to 16 batteries in Parallel, the VoltGo's intelligent BMS ensures all modules within the system are balanced and working together. *Not Applicable to VLRV1280A
IP65 Water and Dust Resistant
Ensure peace of mind during your next fishing or water sports adventure. The VoltGo Elite Series is IP65 protected against dust and offer significant protection against water splashes and sprays, making them suitable for nearly any application.
Superior Construction Quality
The simple maintenance free design allows for a houses a prismatic cell construction, Bluetooth capable BMS within the IP65 rated and impact resistant rugged ABS casing. The detachable lid allows for battery servicing / repair should the need arise*. *performed by qualified service agents only to avoid voiding warranty
Specifications Table
| VLRV1280A | VLRV2560A | VLRV5120A | VLRV2560B | VLRV5120B | VLRV5120C | |
| Voltage (V) | 12.8 | 12.8 | 12.8 | 25.6 | 25.6 | 51.2 |
| Capacity (Ah) | 100 | 200 | 400 | 100 | 200 | 100 |
| Watt Hour | 1280 | 2560 | 5120 | 2560 | 5120 | 5120 |
| Cycle Life | >6000 (0.5C to 80% DoD) | |||||
| Series (Max) | 4S | No | ||||
| Parallel (Max) | 4P | 16P | 16P | 16P | 16P | 16P |
| Length (mm) | 330 | 460 | 460 | 460 | 460 | 460 |
| Depth (mm) | 172 | 220 | 320 | 220 | 320 | 320 |
| Height (mm) | 220 | 212 | 247 | 212 | 247 | 247 |
| Weight (kg) | 11.2 | 25 | 41 | 25 | 41 | 41 |
| Terminals | M8 | |||||
| Compliances | UL1973, UN38.3, IEC62619 | |||||
With 6000+ cycles, IP65 rated Flame retardant and serviceable case design with in-built fire suppression, adaptable mounting & integration options, the VoltGo Elite series is a range worth exploring for your application...
Click here to view the full range
Product Brochures
VoltGo 2560/5120 Range
VoltGo VLRV1280A
