Fronius Wind Speed Sensor
Fronius Wind Speed Sensor 42,0411,0027
Sensors for measuring additional values. Integrating sensors into a PV system enables additional measured values, such as irradiation and ambient temperature, to mention just a couple, to be recorded.
This sensor measures the exact wind velocity. It is a logical addition to the other sensors and completes the private weather station.
Model Number 42,0411,0027
| Dimension / Length | 85mm |
| Sensor | Cup Anemometer with reed contact |
| Output Signal | Rectangle: Low ≤ 0.5V / High ≥ 4.5 V |
| Calibration Factor | 5.22 Hz = 1 km/h 18.79 Hz = 1 m/s From software ver. of Fronius Sensor Card/Box 1.1.0.28: 1.45 Hz = 1 km/h 5.22 Hz = 1 m/s |
| Threshold | 2.5 m/s wind speed |
| Resolution | 1 m/s 1 km/h |
| Tolerance | ±5% from 5 m/s upwards |
| Ingress Protection | IP54 |
| Permissible ambient temperature | -20°C - +60°C |
| Connection cable | 2m Cu cable, exposed ends, ferrules, UV-resistant |
| Max. cable length | 30m |
_
| Selling Unit | EACH |
|---|---|
| Model No | Wind Speed Sensor |
| Brand |
|
| Original Brand | Fronius |
| Description | Fronius Wind Speed Sensor 42,0411,0027 |
| Application | Residential and Light Commercial Solar storage, Off-Grid systems |
| Height | 85mm |
| Categories |
Inverter Chargers Inverter Accessories Fronius Accessories |
