Fronius Wattpilot Flex Home 22 C6
Fronius Wattpilot Flex Home 22 C6 1-phase/3-phase electric car charger 4,240,187
Fronius offers the perfect combination of elegant design and state-of-the-art technology with the Wattpilot Flex. Our electric car charger captures every ray of sunlight from your PV system* and charges your electric car optimally for the next day.
Intelligent charging modes, allow you to use your self-generated solar power cost-effectively and efficiently and, if necessary, increase the range of your car for the next day with cheap electricity from the grid.
*Additional components are required for charging with PV surplus. All details can be found in the operating instructions.
Your energy, your e-mobility
The PV-optimised wallbox dynamically adapts the charging process to the available solar power. This means that the surplus PV power generated is always used optimally to charge your electric car efficiently and cost-effectively.
There are two intelligent charging modes to choose from: Eco Mode uses your solar power first, while Next Trip Mode ensures that exactly the right amount of energy is charged at a specific time for your next journey at the lowest possible cost. If you have a PV system, the Fronius Wattpilot Flex helps you save on charging and also increase your self-consumption.
Efficiency meets elegance
The Fronius Wattpilot Flex can automatically switch between 1-phase and 3-phase charging. This enables charging with a low starting power (1-phase with 1.38 kWh) when there is a PV surplus. When there is a higher PV surplus, it makes sense to switch to 3-phase operation, as 1-phase charging is limited. In this way, the full potential of the solar energy is utilised.
The modern, elegant design encloses its outstanding functionality.
Intuitive user interface, touch buttons and clear menu navigation
The Fronius Wattpilot Flex offers a user-friendly interface with intuitive touch buttons and clear menu navigation. Integrated WLAN and LAN interfaces allow easy integration into your home network.
The Solar.wattpilot app allows you to conveniently control and monitor the wallbox via smartphone or tablet - anytime, anywhere. Plus, with RFID* technology, you can manage different user profiles and always have full control over all charging processes.
Specifications:
1. Input Data
| Range | Wattpilot Flex Home 22 C6 |
|---|---|
| Single or three phase | Automatically switch between 1-phase and 3-phase |
| Maximum charging power | 1-phase: 7.36kW; 3-phase: 22kW |
| Grid supply types | TT / TN / IT |
| Grid connection | 5-pole screw terminal |
| Nominal voltage | 1-phase: 230/240V; 3-phase: 400/415V |
| Rated current (configurable) | 6–32A (1-phase or 3-phase) |
| Grid frequency | 50Hz |
| Charging cable | 6m cable with type 2 plug |
2. General Data
| PV optimisation | Dynamic PV surplus charging from 1.38 - 22 kW (at 230V / 400V) (automatic 1-/3-phase switching) |
|---|---|
| Energy meter | Standard meter (non-calibrated) |
| Standby consumption | 3.5 - 6.8W (depending on the settings) |
| Installation | Indoor and outdoor installation |
| Protection class | IP66 |
| Ambient temperature | –25°C to +45°C |
| Air humidity | 5-95% (non-condensing) |
Related Products
Wattpilot RFID Tags for personalisation
| Selling Unit | EACH |
|---|---|
| Model No | Wattpilot Flex Home 22 C6 |
| Brand |
|
| Original Brand | Fronius 4,240,187 |
| Description | Fronius Wattpilot Flex Home 22 C6 1-phase/3-phase electric car charger 4,240,187 |
| Application | Electric Vehicles, E-mobility |
| Width | 195mm |
| Height | 325mm |
| Length / Breadth / Depth | 105mm |
| Weight | 5.4kg |
| Categories |
Battery Chargers / Analysers / Testers EV Charging Solutions Fronius Fronius EV Charging |
| Data Sheet |
|
Login to MI Link for pricing
Login for Pricing
MI Link is a dealer-only portal. If you are not a current MI account holder register for an account
INSTALLATION TO AUSTRALIAN STANDARDS REQUIRED
