Victron Energy LFP-LSP12.8/100NG

12.8V 100Ah LiFePO4 SuperPack NG

The Lithium SuperPack NG battery is a drop-in replacement for standard lead -acid batteries in RVs and recreational vehicles. Designed for extended off -grid use, it provides ample capacity to power the complete electrical system, including high -demand appliances. Its form factor and terminal layout ensure easy installation in a wide range of  vehicles such as large trucks, SUVs, a nd RVs.

The multiple protections, including an advanced BMS, Bi-directional e-switch, External Feeback switch and Overpressure vent), BIG 2.0C continuous peak current delivery and sub-zero charging capability means the Lithium SuperPack NG range is now an even more attractive option a for lead acid replacement.

Bluetooth monitoring and control:
Includes Bluetooth Smart for wireless configuration, monitoring, and firmware updates via the VictronConnect App . The Instant Readout function displays key data such as state of charge (SoC), battery temperature, warnings, and alarms directly in the device list without the need to connect.

Built-in BMS and battery monitor:
Integrates cell balancing, protection, and monitoring functions to ensure optimal performance and safety throughout the battery’s service life.

External Feedback Signal (EFS):
Provides a battery voltage signal limited to 250 mA. The EFS signal serves as an External Disconnection Signal (EDS) to trigger an event for redundant system protection. Additionally, the EFS can be configured as an External Charging Signal (ECS), based on the low SoC pre-alarm threshold, to activate a charger start signal .

Self-heating function:
Maintains the battery temperature above the minimum safe charging limit to ensure reliable operation in cold environments. Two heating modes are available:

• Charger mode : the heater is powered by the connected charger and activates automatically when the cell temperature drops below 0 °C before charging (default).
• Auto mode : The battery powers the heater to keep the cells above the minimum safe charging temperature for immediate charging. This is limited by the battery’s internal energy; if SoC falls below the Low SoC threshold, the heater is disconnected and charging remains unavailable.

LED status indication:
Two integrated LEDs indicate Bluetooth connectivity, warning and alarm conditions, or firmware update status.

On/Off push button:
Push button for switching the battery on or off, disabling both charging and discharging functions to allow safe operation and extended storage time.

High efficiency:
Operating efficiency 93 %.

Parallel connection:
Supports parallel connection of an unlimited number of batteries to increase total energy capacity. The total system current should not exceed the maximum current that a single battery can safely interrupt.

Configurable discharge floor:
Defines a minimum state of charge to avoid excessive discharge while keeping reserve capacity. When the limit is reached, VictronConnect shows a Low SoC alarm and the Allowed to Discharge (ATD) indicator turns off until the state of charge rises above the set threshold.

Specifications:

• Cycle life: 2500 cycles (80% DoD) @ 25Deg Celcius
• Max. continuous discharge current (2.0C): 200A
• End of discharge voltage: 11.2V
• Charge voltage: 13.5V - 14.2V
• Float voltage: 13.5V
• Max. cont. charge current: 100A
• Operating Discharge temperature: -30°C to +60ºC
• Operating Charge temperature: -30°C to +60ºC
• Storage temperature: +10°C to +30ºC (recommended)
• Humidity (non-condensing): max. 90%
• Protection class: IP65

Safety Vent: The Victron energy SuperPack NG Lithium batteries come standard with a Safety vent.

The 3/4” threaded connection is provided solely for venting possible gases. It is not designed for cooling the battery and must not be connected to water, liquids, or any other media.

Under extreme fault conditions, such as severe internal failure or multiple protection mechanisms failing, the battery may release gases through its internal safety valve. The 3/4-inch threaded connection is provided to allow controlled venting of such gases. It must not be obstructed.

Recommended Chargers:

Victron Energy Blue Smart IP65 12V 15A BPC121531014R

Victron Energy Blue Smart IP22 12V 20A Single Output BPC122042012

Victron Energy Orion XS DC to DC Charger 12-12V 50A ORI121217050
