New Enepower XD Outdoor Cabinets

Introducing the next evolution of Enepowers popular outdoor battery and power equipment cabinet range - the XD Series.

The smart cabinet design has been improved to now accommodate a wider range of modules up to 530mm in depth, providing more diversity to your system designs and components.

Built from the solid foundation of the current cabinet range, and from feedback received from our customers, the XD Series is the next evolution of the Enepower range, designed for the practical demands of outdoor power projects, with greater module space, robust construction, thermal-management options and flexibility across different system configurations.

Cabinet enhancements include:

• Ability to accommodate modules up to 530mm in depth offering greater flexibility
• 1000A rated copper busbars as standard across the range
• Addition of a full length slotted mounting board (EBC25H only)

This in addition to the many amazing features the Enepower cabinet range offers such as:

• 10mm NBR Insulation throughout
• Multiple cable fixing points to reduce installation time
• Powder coated heavy duty construction
• Adjustable brackets to accommodate different battery modules
• Key & pad lockable door handles with 3 point locking mechanism.

Range Models:

EBC25H-XD-ODAIR: Storage for up to 25.6 kWh

All-in-one IP55 Rated A/C Cooled Dual Compartment Outdoor Battery Cabinet for up to 5 x 4RU size 19" Modules (up to 530mm deep), and associated power system components

EBC25H-XD-ODFAN: Storage for up to 25.6 kWh

All-in-one IP55 Rated Fan Cooled Dual Compartment Outdoor Battery Cabinet for up to 5 x 4RU size 19" Modules (up to 530mm deep),  and associated power system components

EBC40H-XD-ODAIR: Storage for up to 46.08 kWh

All-in-one IP55 Rated A/C Cooled Dual Compartment Outdoor Battery Cabinet for up to 9 x 4RU size 19" Modules (up to 530mm deep),  and associated power system components

EBC40H-XD-ODFAN: Storage for up to 46.08 kWh

All-in-one IP55 Rated A/C Cooled Dual Compartment Outdoor Battery Cabinet for up to 9 x 4RU size 19" Modules (up to 530mm deep),  and associated power system components

Enepower is our proprietary range of custom battery, charger and power solutions, developed from our experience supporting off-grid, back-up power and energy-storage projects. If you're looking for a reliable storage solution for your next system, check out the Enepower Cabinet range today
